Introducing New Advances in hand-held aerosol firefighting
Meet the New X-Tinguish® X-Treme
Aerosol Fire Suppression Tool

​

The World’s Most Advanced Aerosol Firefighting Tool!

JUST GOT BETTER!!

This is the long awaited upgrade model replacing the World famous X-Tinguish® FST

​

Request more info
holding the xtreme 11.png

Seconds count when a fire breaks out. Early use of the X-Treme will knockdown the flames, greatly reduce the temperature (by as much as 1,000°F in 60 seconds or less), reduce the need for water by as much as 80% and stop the fires propagation.



The X-Tinguish® X-Treme is designed for mobile total flooding fire suppression applications on land and sea. The X-Treme is a highly effective tool for the suppression of early stage and fully developed fires; preventing flash-over and back-draft.



The unit offers dual protection for Firefighters as it will lower the temperature to under the self-ignition temperature of the fire gasses. The second safety feature is the aerosol itself; once it is active in the atmosphere, the fire gasses present are inerted and cannot be ignited.

​

​

The X-Tinguish® X-Treme and it's predecessors have been installed in thousands of locations globally. The units are in-use from New Zealand to the Arctic Circle covering the globe on every continent except Antarctica.

​

<!-- Google Tag Manager -->

<script>(function(w,d,s,l,i){w[l]=w[l]||[];w[l].push({'gtm.start':

new Date().getTime(),event:'gtm.js'});var f=d.getElementsByTagName(s)[0],

j=d.createElement(s),dl=l!='dataLayer'?'&l='+l:'';j.async=true;j.src=

'https://www.googletagmanager.com/gtm.js?id='+i+dl;f.parentNode.insertBefore(j,f);

})(window,document,'script','dataLayer','GTM-WTPZ2M9');</script>

<!-- End Google Tag Manager -->

<!-- Google Tag Manager (noscript) -->

<noscript><iframe src="https://www.googletagmanager.com/ns.html?id=GTM-WTPZ2M9"

height="0" width="0" style="display:none;visibility:hidden"></iframe></noscript>

<!-- End Google Tag Manager (noscript) -->

NEW UPGRADES INCLUDE

•MODIFIED INTERIOR & INSULATION FOR SAFER USE!

•LIGHTER UNIT WITHOUT SACRIFICING COVERAGE!

•NO VISIBLE FLAMES ON DEPLOYMENT!

WHO NEEDS THE X-TREME?

  • Firefighters (all types)

  • First Responders (all types)

  • Industrial users (all industries)

  • Commercial users (all industries)

  • Maritime (commercial and recreational)

  • Camp owners (remote)

  • Utility companies (electric and natural gas)

  • rural and remote location homeowners



SPECIFICATIONS

Total weight……………………………13.00Lbs. / 6.3 kg.

Compound weight…………………. ...6.50 Lbs. / 2.9kg.

Volume coverage……………………  ≤ 5,300cu.ft. / 150 m³

Discharge time………………………...30 seconds

Activation method………………...….Manual pull pin

Operational to………………………...-65°F / -55°C below zero

The X-Tinguish® X-Treme (Aerosol Fire Suppression Tool) is used by Firefighters, Police, Armed forces and First Responders as a highly effective suppression tool against early stage and fully developed fires. The X-Tinguish® X-Treme is non-pressurized and is deployed manually by pulling a pin which will set off an electronic ignition system.



After triggering the X-Tinguish® X-Treme generator, an aerosol mist is generated, which expands volumetrically, flooding the space and suppressing the flames within seconds. The X-Tinguish® X-Treme is designed for the use on class A, B, C and K fires.


the facts....

  • Offers extraordinary knock down as well as fast suppression capabilities

  • Reduces temperatures by as much as 1,000°F in 30 seconds

  • Can cut water usage by as much as 80%, when used properly

  • The aerosol is SNAP listed by the US EPA (Aerosol A, SFE)

  • Is environmentally friendly  (ODP  0%, GWP  0%)

  • Does not reduce or deplete (O²) oxygen

  • Can eliminate flashover and backdraft

  • Is Non-Toxic, Non-Corrosive and Non-Conductive

  • Highly Efficient and Suitable against A-B-C-K class fires

  • IS NOT  pressurized!

  • Has a 5 year battery life

  • Has a 15 year shelf life

  • Includes a new “R-pin” that protects the igniter pin from                      being accidentally removed.

  • LED light turns red when the unit is activated!

firefighter extended.png
The X-Tinguish FST is uncomparable when used in an enclosed attic!

Class A

​

​

​

​

​

Class B

​

​

​

​

​

​

Class C

​

​

​

​

​

​

Class K

class a.png
CLASS B LIQUID.png
CLASS C.png
class K.png

a few videos...

<!-- Global site tag (gtag.js) - Google Analytics -->
<script async src="https://www.googletagmanager.com/gtag/js?id=UA-34294917-1"></script>
<script>
  window.dataLayer = window.dataLayer || [];
  function gtag(){dataLayer.push(arguments);}
  gtag('js', new Date());

  gtag('config', 'UA-34294917-1');
</script>


Correct and timely usage of the X-TINGUISH® X-TREME can prevent and / or significantly reduce the damage caused by fires. The X-TINGUISH® X-TREME allows its user the ability to mitigate the danger posed by flash-over and back-draft to firefighters and first responders. While no device can prevent or totally suppress the harmful effects of a fire, the X-TINGUISH® X-TREME is a unique way to combat fires and represents a giant advance in fire-suppression technology from water or other chemical-based methods.



The X-TINGUISH® X-TREME  is a small, portable unit that contains potassium based chemical components.  It is designed to be a first-use method to combat class A, B, C, and K fires.



When the device is deployed at the scene of a fire, the X-TINGUISH® X-TREME releases a cloud of aerosol containing the potassium components, interrupting the chain reaction in the flame.

​

When utilized and deployed according to the instructions in the Operation Manual, the X-TREME provides an extremely effective method of fire suppression.

​

About video two:

​

Two videos from two different cameras. We used a FLIR K53 Thermal Imaging Camera and a GoPro Hero9 to give the best quality view of what exactly happens inside the Flash-over chamber when the X-Tinguish® X-Treme is used on a violent fire.


You will see the GoPro Hero9 video first and then the exact time frame from the FLIR K53. Pay attention to the colors in the background during the FLIR video. Deeper red tones indicate a much hotter area than yellow. The chamber has been burning for about 50 minutes to an hour when this video was taken, The metal walls have had plenty of time to heat up and retain the higher temps. This will be indicated by yellow. You will notice that within a very short time span the reds and oranges will completely disappear. This ,along with the numerical data show that heat is being eliminated from the sealed chamber in quick fashion.

​

After the X-Tinguish® X-Treme is deployed, there is an 8-second digital countdown before the unit activates. Once activated, the units condensed aerosol fire suppression takes over. It releases a potassium based fire suppressant that is non-toxic and also poses no problem to the environment.

Within 60 seconds the temperature will drop up to 1,000°F / 538°C and the flames will be knocked down and held.

​

Flame Guard USA has been involved with this technology since 2012. Our motto is "Innovation in Fire Suppression".

The X-Tinguish® X-Treme makes sense for just about every industry on land and sea.

​
